| PART # | ITEM | MODEL | FINISH | DIA | WIDTH | BORE | OFFSET | BSM | LUGS | BP1 | BP2 | CAP # |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 9101-2137C | 9101 | Americana | Chrome | 20 | 10 | 106 | -25 | 4.52 | 6 | 135 | 139.7 | C109101C |
| 9101-2152C | 9101 | Americana | Chrome | 20 | 10 | 87 | -25 | 4.52 | 5 | 127 | 139.7 | C109101C |
| 9101-2176C | 9101 | Americana | Chrome | 20 | 10 | 130.8 | -25 | 4.52 | 8 | 165.1 | 170 | C109101C |
| 9101-2178C | 9101 | Americana | Chrome | 20 | 10 | 124.1 | -25 | 4.52 | 8 | 180 | C109101C | |
| 9101-2237C | 9101 | Americana | Chrome | 20 | 12 | 106 | -44 | 4.77 | 6 | 135 | 139.7 | C109101C |
| 9101-2137M | 9101 | Americana | Satin Black Milled | 20 | 10 | 106 | -25 | 4.52 | 6 | 135 | 139.7 | C109101MB |
| 9101-2152M | 9101 | Americana | Satin Black Milled | 20 | 10 | 87 | -25 | 4.52 | 5 | 127 | 139.7 | C109101MB |
| 9101-2176M | 9101 | Americana | Satin Black Milled | 20 | 10 | 130.8 | -25 | 4.52 | 8 | 165.1 | 170 | C109101MB |
| 9101-2178M | 9101 | Americana | Satin Black Milled | 20 | 10 | 124.1 | -25 | 4.52 | 8 | 180 | C109101MB | |
| 9101-22437C | 9101 | Americana | Chrome | 22 | 14 | 106 | -76 | 4.51 | 6 | 135 | 139.7 | C109101C |
| 9101-2237M | 9101 | Americana | Satin Black Milled | 20 | 12 | 106 | -44 | 4.77 | 6 | 135 | 139.7 | C109101MB |
| 9101-22437M | 9101 | Americana | Satin Black Milled | 22 | 14 | 106 | -76 | 4.51 | 6 | 135 | 139.7 | C109101MB |
| 9101-22476C | 9101 | Americana | Chrome | 22 | 14 | 130.8 | -76 | 4.51 | 8 | 165.1 | 170 | C109101C |
| 9101-22478C | 9101 | Americana | Chrome | 22 | 14 | 124.1 | -76 | 4.51 | 8 | 180 | C109101C | |
| 9101-2252C | 9101 | Americana | Chrome | 20 | 12 | 87 | -44 | 4.77 | 5 | 127 | 139.7 | C109101C |
| 9101-2276C | 9101 | Americana | Chrome | 20 | 12 | 130.8 | -44 | 4.77 | 8 | 165.1 | 170 | C109101C |
| 9101-2937C | 9101 | Americana | Chrome | 20 | 9 | 106 | 0 | 5 | 6 | 135 | 139.7 | C109101C |
| 9101-2976C | 9101 | Americana | Chrome | 20 | 9 | 130.8 | 0 | 5 | 8 | 165.1 | 170 | C109101C |
| 9101-22476M | 9101 | Americana | Satin Black Milled | 22 | 14 | 130.8 | -76 | 4.51 | 8 | 165.1 | 170 | C109101MB |
| 9101-22478M | 9101 | Americana | Satin Black Milled | 22 | 14 | 124.1 | -76 | 4.51 | 8 | 180 | C109101MB | |
| 9101-2252M | 9101 | Americana | Satin Black Milled | 20 | 12 | 87 | -44 | 4.77 | 5 | 127 | 139.7 | C109101MB |
| 9101-2276M | 9101 | Americana | Satin Black Milled | 20 | 12 | 130.8 | -44 | 4.77 | 8 | 165.1 | 170 | C109101MB |
| 9101-2278M | 9101 | Americana | Satin Black Milled | 20 | 12 | 124.1 | -44 | 4.77 | 8 | 180 | C109101MB | |
| 9101-2937M | 9101 | Americana | Satin Black Milled | 20 | 9 | 106 | 0 | 5 | 6 | 135 | 139.7 | C109101MB |
| 9101-2937M18 | 9101 | Americana | Satin Black Milled | 20 | 9 | 106 | 18 | 5.71 | 6 | 135 | 139.7 | C109101MB |
| 9101-2952M | 9101 | Americana | Satin Black Milled | 20 | 9 | 87 | 0 | 5 | 5 | 127 | 139.7 | C109101MB |
| 9101-2952M18 | 9101 | Americana | Satin Black Milled | 20 | 9 | 87 | 18 | 5.71 | 5 | 127 | 139.7 | C109101MB |
| 9101-2976M | 9101 | Americana | Satin Black Milled | 20 | 9 | 130.8 | 0 | 5 | 8 | 165.1 | 170 | C109101MB |
| 9101-2976M18 | 9101 | Americana | Satin Black Milled | 20 | 9 | 130.8 | 18 | 5.71 | 8 | 165.1 | 170 | C109101MB |
| 9101-2978M | 9101 | Americana | Satin Black Milled | 20 | 9 | 124.1 | 0 | 5 | 8 | 180 | C109101MB | |
| 9101-2978M18 | 9101 | Americana | Satin Black Milled | 20 | 9 | 124.1 | 18 | 5.71 | 8 | 180 | C109101MB | |
| 9101-2997M | 9101 | Americana | Satin Black Milled | 20 | 9 | 110 | 0 | 5 | 5 | 139.7 | 150 | C109101MB |
| 9101-2997M18 | 9101 | Americana | Satin Black Milled | 20 | 9 | 110 | 18 | 5.71 | 5 | 139.7 | 150 | C109101MB |
